| GENERAL
SPECIFICATIONS |
|
TRANSMITTER
SPECIFICATIONS |
| Frequency
Coverage............ |
28.000
- 29.699 MHz
|
|
Frequency
Response........... |
400
- 3500 Hz |
| RF
Power Output.................. |
30
Watts PEP |
|
Frequency
Tolerance........... |
0.0005% |
| Modes................................... |
AM,
FM, USB, LSB |
|
Frequency
Accuracy........... |
+10
ppm or better |
| Tuning
Steps......................... |
1
kHz, 10 kHz or 100 kHz |
|
Carrier
Suppression............. |
-40
dB or better |
| Memory
Channels................. |
5
Channels |
|
Unwanted
Sideband............. |
-50
dB or better (1 kHz tone) |
| Antenna
Impedance.............. |
50
ohms, unbalanced |
|
Spurious
Emission................ |
-50
dB or better |
| Power
Requirement.............. |
12
- 16 Volt DC |
|
FM
Deviation......................... |
+/-2
kHz |
| Dimensions........................... |
2(H)
x 6(W) x 7.5(D) in |
|
Current
Consumption............ |
6
amps at max. output |
| Weight................................... |
2.9
lbs. (approx.) |
|
Microphone
Impedance......... |
600
ohms, ECM |
| FEATURES |
|
RECEIVER
SPECIFICATIONS |
| Microprocessor
Controlled |
|
Circuit
Type........................... |
Superheterodyne, |
| Variable
RF Output Power |
|
Dual
Conversion |
| 5
Digit LCD Frequency Display |
|
Intermediate
Frequencies..... |
1st
: 10.695 MHz |
| S/RF
Meter |
|
2nd
: 455 kHz |
| Frequency
Scan |
|
SSB
: 10.695 MHz |
| Noise
Blanker |
|
Sensitivity
(10 dB S+N/N)..... |
SSB
: 0.25µV |
| Last
Channel Recall |
|
FM
: 0.3µV (dB SINAD) |
| Automatic
Call Frequency Control (FM 29.600 MHz) |
|
AM
: 0.5µV |
| Scanning
Microphone |
|
Selectivity............................. |
AM
/ FM : 6.0 kHz (-6 dB) |
| Offset
(Split) Frequencies |
|
AM
/ FM : 18 kHz (-60 dB) |
| Night
Illuminated Display |
|
SSB
: 4.2 kHz (-6 dB) |
| Receive
Audio Tone Control |
|
SSB
: 8.5 kHz (-60 dB) |
| 1
Year Warranty |
|
RIT
Variable Range............... |
+/-1.5
kHz |
| MARS
and CAP Capable (permits required) |
|
Squelch
Range..................... |
0.6µV
to 1mV |
| Extended
Service Contracts Available |
|
Rejection.................... |
80
dB or better |
| Magnum |
|
Adjacent
Channel Rejection.. |
AM
/ FM : 60 dB |
| |
|
SSB
: 70 dB |
| |
Audio
Output Power............. |
2.0
watts into 8 ohms |
| |
THD....................................... |
5%
or better at 500mW |
| |
Current
Consumption............ |
1.5
amp at max. output |
